涡旋式工业冷水机组技术参数
|
型 号 20STB-Model
|
05WSO4
|
10WSO4
|
12.5WSO4
|
15WSO4
|
05WSC4
|
10WSC4
|
12.5WSC4
|
15WSC4
|
制冷剂 Refrigerant
|
R22
|
R407A
|
R22
|
R407A
|
R22
|
R407A
|
R22
|
R407A
|
名义制冷量
Rated cooling capacity
|
×1000 kcAHl/h
|
12.8
|
13.3
|
26.6
|
25.0
|
30.8
|
30.4
|
38.9
|
37.6
|
kW
|
14.9
|
15.4
|
30.9
|
29.1
|
35.9
|
35.3
|
45.2
|
43.7
|
压缩机输入功率 kW×台数
Comp.input PowerX QTY(KW)
|
3.3×1
|
3.1×1
|
6.3×1
|
6.2×1
|
7.2×1
|
7.5×1
|
9.6×1
|
9.4×1
|
机组运行电流 Comp.current(A)
|
6.9
|
6.7
|
14.0
|
13.6
|
15.1
|
15.3
|
20.0
|
19.3
|
电 源 Power supply
|
3φ-380V-50Hz
|
保护装置 Protection device
|
逆相保护、缺相保护、过流保护、排气温度保护、高低压保护、低温保护、预留水流保护接口
Phase Peversion Protection、Phase Lack Protection、Overload Current Protection、The Reserved Water Protection Interface
|
制冷回路 Number of refrigeration circuits
|
1
|
1
|
1
|
1
|
能量控制% Capacity control
|
0,66,100
|
制冷剂 Refrigerant
|
R22
|
冷凝器 Condenser
|
壳管式 Shell-and-Tube Type
|
冷凝器
Condenser
|
进出口管径Dia.Of Pipe(inch)
|
1-1/2″
|
1-1/2″
|
2″
|
2″
|
水侧最高承压
Water Side Max Pressure (Mpa)
|
1
|
冷却水流量Cooling Water Folw (L/m)
|
52
|
53
|
107
|
101
|
123
|
123
|
157
|
152
|
水压降Water Pressure drop(Kpa)
|
22
|
22
|
29
|
29
|
31
|
31
|
41
|
41
|
蒸发器 Evaporator
|
壳管式 Shell-and-Tube Type
|
蒸发器
Evaporator
|
进出口管径Dia.Of Pipe(inch)
|
1-1/2″
|
1-1/2″
|
2″
|
2″
|
水侧最高承压Water Side Max Pressure (Mpa)
|
1
|
冻水流量
Chilled Water Folw (L/m)
|
43
|
44
|
89
|
83
|
103
|
101
|
130
|
125
|
水压降Water Pressure drop(Kpa)
|
14
|
14
|
23
|
23
|
28
|
28
|
30
|
30
|
运转噪音 Running noise dB(AH)
|
60
|
75
|
75
|
75
|
整机重量 Total Weight(kg)
|
150
|
260
|
320
|
450
|
